Great: Minimal signs of use.\n Wireless Audio Receiver \n

The SLX4 receiver brings unprecedented ease of use to wireless with Automatic Frequency Selection and Automatic Transmitter Setup. For use with SLX Wireless.

\n

With included rack hardware and detachable antennas, it is ready for immediate installation right out of the box.

\n

Model SLX4L is available with logic output for use with software echo cancellation and remote battery life monitoring. Logic-enabled transmitters include MX690 and MX890.

\n

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

\n

Key Features

\n\n

\n
• Automatic Frequency Selection
\n
• Automatic Transmitter Setup
\n
• 960 Selectable frequencies across 24 MHz bandwidth
\n
• Detachable 1/4 wave antennas
\n
• Microprocessor-controlled diversity
\n
• RF presence LED
\n
• 5-segment audio meter
\n
• Multi-function, backlit LCD
\n
• Low battery indicator
\n
• Frequency and power lockout
\n
• Rugged metal chassis
\n
• Volume control on rear of unit
\n
• 1/2 rack design
\n
• Furnished rack hardware
\n
• Non-slip bumpers for use out of rack
\n
• XLR and 1/4 inch outputs
\n

\n

Technical Specifications

\n

Dimensions\n42mm X 197mm X 134mm (H x W x D)\nWeight\n816 g (1 lb 13oz.)\nHousing\nGalvanized steel\nSensitivity\n-105 dBm for 12 dB SINAD, typical\nPower Requirements\n12-18 V DC @ 150 mA, supplied by external power supply (tip positive)\nConfiguration\nImpedance balanced\nMaximum Audio Output Level Ref. ±38 kHz deviation with 1 kHz tone\nXLR connector: -13 dBV (into 600 ohm load)\n6.35 mm (1/4 inch) connector: -2 dBV (into 3 k ohm load)\nImpedance\nXLR connector: 200 ohm\n6.35 mm (1/4 inch) connector: 1 k ohm\nPin Assignments\nXLR connector: 1=ground, 2=audio, 3=no audio\n6.35 mm (1/4 inch) connector: Tip=audio, Ring=no audio, Sleeve=ground\nImage Rejection\n>70 dB, typical\nVolume Adjustment Range\n0 dB to -25 dB
