JBL VMA2120 8x2, 120W Mixer / Amplifier
Price$698.01
Free Shipping
Free Shipping
from Verona, WI
Listed:over a month ago
Views:142
Watchers:1
Verona, WI, United States
14-Day Return Policy
Enjoy peace of mind with your new gear
Reverb Outlet
Qualified outlet items are 20% savings or more.Learn more
Our users rate Reverb
The JBL VMA Series VMA2120 is a cost-effective mixer/amplifier with low-impedance functionality (4Ω, 8Ω) and high-impedance 70V and 100V output. The VMA2120 is designed with convenient and flexible features to be used by commercial integrators worldwide, ideal for emerging markets. Features 8 inputs and two 120W outputs, with independent bass/treble controls per each output. Works with all JBL CSR-V wall controllers, and offers paging chime and priority muting functionality. Rack-mounting hardware included.
Features- 8 inputs, two 120W outputs
- Independent bass/treble controls on each output channel
- 100V and 70V output, or 4-ohm/8-ohm
- Works with JBL CSR-V wall controllers
- Balanced mic/line inputs; RCA (.775V) inputs
- Max Output Power per Channel: into 4 O or 8 O;1kHz, =0.5% THD - 120W
- Insertion Loss: (70V & 100V outputs) 1dB maximum
- Number of Inputs: 8
- Number of Outputs: 2
- Tone Controls: (Bass and Treble non-detented potentiometers on eachchannel) Bass +/-14dB @ 50Hz; Treble +/-14dB @10kHz
- Input Sensitivity: (to obtain full rated powerinto 8 O load) MicInput: 5.5mVRMS Line Input: 1.3VRMS RCA Input (stereo in): 130mVRMS
- Frequency Response: (measured at 2.83VRMS into rated load impedanceat any output) 4/8 O Output: 20Hz - 20kHz, +/-2dB;70V/100V Outputs: 80Hz -15kHz +/-3dB
- Total Harmonic Distortion (THD): (measured at 2.83VRMS into rated load impedanceat any output) Power Amp Output:< 0.5%, 20Hz - 20kHz
- Signal to Noise Ratio: (Ref. Rated Power, mixer levels@ min., mastervolume @ max. A-weighted) >76dB
- Input Impedance: (nominal) Mic: 400 O Line: 20 kO (balanced) RCA: 50kO
- Phantom Power: 27VDC
- Crosstalk: (reference rated power, volume at mid position, 1kHz) -70dB
- Nominal AC Line Voltages: 100V, 120V, 220V,220-240V, 50/60 Hz
- Minimum LoadImpedance: (Low Impedance Output, 70V Output, 100V Output) 4 O, 40 O, 80 O
- Operating Temperature/Humidity: 0°C to 35°C @ 95% R.H.(non-condensing)
- Storage Temperature: -20°C to 85°C
- Net Weight: 29.3 lb (13.3 kg)
- Dimensions (WxDxH): 17.0" x 16.3" x 3.5" (432 x 415 x 88 mm)
| Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
|---|---|
| Brand | |
| Model |
|
| Categories | |
| Format |
|
| Electronics |
|
| Number of Analog Outputs |
|
| Number of Analog Inputs |
|
| Number of Channels |
|
