Sennheiser EW-D 835-S Set (Q1-6) All-In One Digital Wireless System Handheld Set

Up for sale a Sennheiser EW-D 835-S Set (Q1-6) All-In One Digital Wireless System Handheld Set!  We are an Authorized Dealer of Sennheiser!  This item is Brand New / Never Displayed and it comes with the Full Manufacturer's Warranty*.  Unit comes with its Accessories in its Original Packing.

-

SENNHEISER EW-D 835-S HANDHELD SET (Q1-6)

All-in-one digital wireless handheld set for those who sing or speak featuring Sennheiser's renowned e 835 capsule.

Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. Receive state-of-the-art live sound featuring Sennheiser‘s renowned e 835 capsule on a lightweight handheld transmitter with integrated mute switch.

-

FEATURES:

- Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability

- Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance

- Auto scan creates reliable connections with minimal time and effort

- 134 dB audio input dynamic range eliminates need for sensitivity adjustments and preserves every detail

- Elimination of intermodulation enables channels to be placed in an equidistant tuning grid 600 kHz apart

- 56 MHz of tuning bandwidth and equidistant spacing enables up to 90 channels

- 2,240 selectable frequencies allow for fine tuning

- Lithium-Ion battery pack (sold separately) delivers up to 12 hours of operation (up to 8 hours of operation with 2x provided AA batteries)

-

WHAT'S IN THE BOX:

- EW-D EM rack receiver

- EW-D SKM-S handheld transmitter

- MMD 835 microphone module

- MZQ 1 microphone clamp

- 2 rod antennas

- power supply with country adapters

- rackmount set

- 4 rubber feet

- quick guide

- safety guide

- manufacturer declaration sheet

-

SPECIFICATIONS:

Frequency range : 520 - 576 MHz

THD, total harmonic distortion : ≤ -60 dB for 1 kHz @ -3 dBfs input level

Operating temperature : -10 °C - +55 °C (14 °F - 131 °F)

Operating relative humidity : 5 - 95 % (non-condensing)

Audio frequency response : 20 Hz - 20 kHz (-3 dB) @ 3 dBfs

System Latency : 1.9 ms

EW-D EM:

- Dimensions : 212 x 44 x 189 mm

- Weight : approx. 1000 g (without antennas and power supply)

- Current consumption : ≤ 300 mA

- Input voltage range : 11 - 13 V ⎓

- Audio output level : 18 dBu max.

- Transmission power : BLE: max. 10 mW EIRP

MMD 835 (Microphone Module):

- Dimensions : 405 x 350 x 73 mm

- Sound pressure level (SPL) : 154 dB

- Transducer principle : dynamic

- Weight : 3.1 kg

- Pick-up pattern : cardioid

- Sensitivity : 2.1 mV/Pa

EW-D SKM-S (Handheld Transmitter):

- Weight : approx. 304 g (incl. MMD 835 microphone module), approx. 195 g (without microphone module)

- Power supply : 2 AA batteries 1.5 V (alkaline manganese) or BA 70 rechargeable battery pack

- Current consumption : < 300 mA

- Input voltage range : 2.0 - 4.35 V

Transmission power:

- Audio link: 10 mW

- ERP (Range Y1-3): 12 mW ERP

- BLE: max. 10 mW EIRP

Dimensions : 50 x 268 mm (incl. MMD 835 microphone module), 40 x 200 mm (without microphone module)

-

*The full manufacturer's warranty is only valid through us.

All our items are fully verified by our pro technician and/or adjusted by our pro luthier before being very carefully packed by our pro service team here at the shop prior to shipment, buy with confidence!

---------------------------------------------------------------------

Canadian customers must pay any applicable sales taxes.

Please refer to the shipping and payments details for prices.

**Depending on where you are located in Canada, free shipping may not apply to certain heavy or oversize orders.
 You can contact us for confirmation before buying.
