The Wharfedale Diamond 240 is a 2.0 channel standing speaker with audio inputs available via banana jack. As part of the Wharfedale brand, known for its quality audio products, the Diamond 240 model offers a sleek and powerful design for enhancing your home audio experience. Perfect for connecting to various sources of sound, this speaker is ideal for those looking to upgrade their living space with a reliable and high-performing audio system.Features

3-Way Driver Design: The Wharfedale Diamond 240 is a 3-way floorstanding loudspeaker which incorporates a 1" fabric soft-dome tweeter, 5.125 woven kevlar midrange driver, and two 6.5" woven kevlar cone woofers. Finely tuned crossovers guarantee a smooth transition between the tweeter, midrange, and woofers with an enjoyable audible experience, both on and off-axis.

  • Fabric Soft-Dome Tweeter: The 1" tweeter uses a sheer fabric dome and advanced ferrite magnet system, surrounded by a carefully crafted wave guide that encourages outstanding midrange performance too.
  • Woven Kevlar Woofer Cones: Semi-elliptical "break-up" areas on the woven-kevlar woofer cones (including the 5.125" midrange & dual 6.5" woofers) smooth the response through the audible range. The cone edges are treated with a unique diamond pattern rubber surround.

Non-Resonant Cabinet: The speaker cabinet combines layers of particle board and MDF, bonded in a unique structure to damp annoying resonances and block internal sound leakage. The result is that the "noise" and distortion from cabinet walls are buried more than a 35dB below the driver output. Cabinet walls and internal bracing were developed using Wharfedale's latest "Virtual Speaker" software, with the help of Delayed Cumulative Spectral Analysis. The top, bottom, and side walls of the cabinets are finished with a wood veneer (black, rosewood, or walnut), while the baffle is finished with a gloss black lacquer.

Bass Port: Exiting the base of the speaker cabinet is a slot loaded distributed port created by the plinth. This equalizes the air pressure to mimic that inside the cabinet allowing a smooth transition between the pressure variation in the cabinet and the low frequency sound developed in the room.

Dual Binding Posts: The floorstanding loudspeaker has two sets of binding posts connected by jumper-plates. The binding posts will accept bare wire (up to 10AWG), pin connectors, spade connectors, & banana plugs (single only). Using these dual binding posts, you can bi-amp or bi-wire the speakers. Bi-wiring or bi-amping the speaker provides improved bass & treble performance. If you decide to bi-wire or bi-amp, you must remove the jumpers between the terminal posts (failure to do this could result in damage to your amplifier and loudspeakers).

  • Bi-Wiring: Bi-wiring can provide noticeable improvements in the overall transparency of your loudspeakers. Run separate speaker wires to the low & high frequency drivers from a single amplifier (the upper set of binding posts are for the high frequency drivers; the lower set of binding posts are for the low frequency drivers).
  • Bi-Amping: Bi-amping allows you to use separate amplifiers for the high & low frequency sections of your loudspeaker for greater dynamic range & lower distortion. We recommend that your separate amplifiers have identical gain to preserve the speaker's voicing balance.

Spike Feet & Isolation Pucks: The Wharfedale Diamond 240 floorstanding loudspeaker comes with four spike feet for carpet installation. Four isolation pucks with foam padding are also included to protect your hardwood, tile, laminate, and vinyl flooring. The spike feet screw into the bottom of the speaker cabinet's plinth and are adjustable so you can level up the speaker. The spike feet can be placed directly on carpet or set in the isolation pucks to protect hardwood, tile, and laminate, and vinyl flooring. The isolation pucks add approximately 0.25" to the overall height of the speaker.

Product info:

  • 3-way design
  • 1" soft dome tweeter
  • 5-1/8" woven Kevlar midrange driver
  • two 6-1/2" woven Kevlar bass drivers
  • frequency response: 40-20,000 Hz (±3dB)
  • recommended amplifier power: 25-150 watts
  • sensitivity: 89 dB
  • impedance: 4 ohms
  • bass reflex design with slot-loaded port
  • binding posts accept pins, banana connectors, or bare wire
  • two sets of input terminals allow bi-amping or bi-wiring
  • removable grilles
  • 8-1/16"W x 40-5/16"H x 15-9/16"D
  • weight: 47.7 lbs.
