One of the first speakers ever used in a guitar amplifier, the P15N was loaded in the earliest Fender Bassman® and Bandmaster® amps, setting the milestone for those classic tones. The P15N delivers a warm, full bodied tone, with deep basses, and a nice, extended top end. Excellent for all different shades of clean and pushed clean tones.

Guitarist Description: Warm, deep low-end and sparkling highs. Responds to overdrive distortion with a bright edge and lengthy sustain capabilities.

• Lows: Tight/Fat
• Mids: Aggressive
• Highs: Bright
• Overdrive: Edgy

Product Measurements

Diameter: 15 in.
Voice Coil Diameter: 1.5 in.
Depth: 6.6338 in.
Outer Diameter: 15.0787 in.
Inner Diameter: 14.0945 in.
Mounting Hole Bolt Circle Diameter: 14.6457 in.
Magnet Assembly Depth: 2.0078 in.
Mounting Hole Diameter: 0.2362 in.
Nominal Overall Diameter: 385.00 mm
Nominal Voice Coil Diameter: 38.00 mm
Flux Density: 1.26 T
Voice Coil Winding Depth: 10.00 mm
Magnetic Gap Depth: 8.00 mm
Magnet Type: Alnico
Voice Coil Winding Type: Copper
Voice Coil Former: Kapton
Cone Material: Paper
Surround Material: Integrated Paper
Dust Dome Material: Solid Paper
Basket Material: Pressed Sheet Steel
Surround Treatment: No
Voice Coil DC Resistance (Re): 6.22 Ω
Resonance Frequency (ƒS): 77.90 Hz
Mechanical Q Factor (QMS): 6.80
Total Q Factor (QTS): 1.22
Mechanical Moving Mass (MMS): 53.90 g
Mechanical Compliance (CMS): 78.00 µm/N
Force Factor (BxL): 10.49 Wb/m
Equivalent Acoustic Volume (VAS): 62.60 liters
Linear Displacement, maximum (XMAX): 1.00 mm
Reference Efficiency (nO): 2.62 %
Diaphragm Area (SD): 754.80 cm2
Losses Electrical Resistance (RES): 50.00 Ω
Voice Coil Inductance @ 1 kHZ (LE): 0.90 mH
Rated Power: 50.00 W
Musical Power: 100.00 W
Sensitivity @ 1W, 1m: 96.10 dB
