The Power Engine 60 is an all-purpose, multi-function, powered extension cabinet. The PE 60 can be used with any direct recording device or pre-amp, analog or digital, tube or solid state, in stompbox or rackmount formats When plugging your favorite device into a Power Engine, the tone is unaffected. So there’s no need to labor over readjusting all your parameters that would otherwise be colored by a conventional amp.

These handsome cabinets perfectly complement our line of Trademark combo amps. The Power Engine 60 will accept XLR and 1/4” inputs and includes a balanced XLR output to ‘daisy-chain’ with other Power Engine 60s. Knowing that not all rooms are created acoustically perfect, you can compensate for less than ideal environments by adjusting the on-board, active three-band EQ.

Wherever your tones come from, make the Power Engine 60 your destination for portable, pure reproduction.

Model Number

PW60

Input Impedance:10kOhmsNominal Input Level-20dBm to +4dBmOptimal Output Load:8 OhmsPower Output:60WMaximum Power Consumption:120WAC Input Power (factory set):100V, 117V, 230V, 240VCycles:50/60 HzSpeaker:

(1×12) Celestion® Seventy80 Model #CT2112-8 12″, 80W, 8Ω

(2×12) Celestion® Seventy80 Model #CT2112-16 12″, 80W,
16Ω each 8Ω Total Load

(4×10) Eminence® Model #ET-2110-8, 10″, 50W, 8Ω each,
8Ω Total Load

Cabinet Dimensions:

(1×12) 20″l x 11″w x 18″h

(2×12) 26″l x 12″w x 19″h

(4×10) 22″l x 12″w x 22″h

Weight:  1×12: 33 lbs; 2×12: 39 lbs; 4×10: 43 lbs
