VINTAGE KING APPROVED

This item has been carefully inspected, tested and serviced by our expert tech team. All vintage, used and open-box items we sell are backed by an industry-leading warranty. Expand your studio with confidence knowing that we have you covered.

WesAudio _Hyperion 500 Series Parametric EQ #241163 (Used)

The WesAudio Hyperion 500 Series Parametric EQ is fully analog parametric EQ with +24 dBu of headroom. It features a lot of innovative improvements that no other processor on the market provides. It's innovative design utilizes 18 VCAs per channel to provide noiseless parameter changes and very musical nature. HYPERION is next product in NG500 line where total recall is implemented through front panel USB socket, or TITAN chassis.

FEATURES:

• +24 dBu of headroom
• Stereo / Dual mono / Mid/Side operation mode
• 4-Band EQ with switchable gain range for 5 db or 15 dB boost or cut per band:
• HPF with 12 dB/Oct or 6 dB/Oct slopes
• Each band features its own Bypass switch
• Essentially Noiseless parameter changes
• Proprietary THD implementation
• Flexible DAW/Live plug-in control for instant recall
• 12 touch sensitive encoders allows to record automation
• True bypass
• In and OUT metering with clip detection
• A/B compare feature

SPECIFICATION:

• Frequency response 10 Hz-150 kHz (-2 dB)
• THD+N all bands gain “0” 0.03% (1 kHz,0 dBu)
• THD+N +15dB band boost <0.15% (1 kHz,0 dBu)
• Input impedance 10k ohm
• Output impedance < 100 ohm
• Max signal level +24dBu
• Crosstalk < -100 dB
• THD (MID switch) 1%
• THD (HIGH switch) 2.5%
• Power consumption 150mA per rail

USED ITEM WARRANTIES

Vintage King offers an industry-leading level of technical service and warranty support on our used and vintage items. Our used item warranty periods are as follows:

• Analog Outboard Gear – 1 Year
• Microphones – 1 Year (excluding capsules, tubes, and ribbon elements)
• Speakers – 1 Year (excluding drivers)
• Digital Outboard Gear – 30 Days
