ONE PEDAL. THREE EXPRESSIONS
The main treadle delivers a wide sweep with silky-smooth response. The XXP-1 isn't just an expression pedal — it's three of them in one rugged aluminum shell. Kick in a toe-switch function with EXP2 without ever leaving the treadle. And with Xotic's proprietary heel control knob, fine-tune a second parameter in real time — live, on the fly, with a simple touch of your heel. It's expression control built for players who need more than one thing to move at once.
THE LAST EXPRESSION PEDAL YOU'LL NEED. EVERY FUNCTION. ANY JACK. NO SOLDERING. COMPLETE PEDALBOARD FREEDOM.
Each jack can be configured for either TRS or TS expression control via internal DIP switches, so the XXP-1 adapts to your amp sim, modeler, or MIDI controller instead of forcing you to adapt to it. Every expression function on the XXP-1 can be assigned to any of its output jacks. Thanks to the quick-connect internal wiring, you can reconfigure the jack layout in minutes — no soldering required.
EXPRESSION, ENGINEERED
Whether you're running a digital rig with multiple expression-hungry parameters or just want one pedal that can serve as both a wah and a volume pedal without swapping cables, the XXP-1 was built for that setup. One footprint. Three points of control. Zero compromise on feel.

• Dimensions: (W/D/H): D 8.27” (210mm) W 3.94” (100mm) H 2.64" (67mm)
• Weight: 2 lb. (910g)
• Treadle Pedal Expression Output: 20K ohm TRS or TS Switchable
• Heel Knob Expression Output: 20K ohm TRS or TS Switchable
• Toe Switch Output: TS Momentary Switch
