Shure ULXD14 Digital Wireless Bodypack System (G50)

Overview

The Shure ULXD14 is a complete wireless bodypack system combining the ULXD4 receiver and ULXD1 bodypack transmitter. It provides pristine 24-bit digital audio with reliable RF performance for presentations, houses of worship, theaters, and live events.

Key Features

• Operating range: 100 m (330 ft) line-of-sight
• Latency: 2.0 ms (standard) / 1.0 ms (low latency mode)
• Battery life: 2× AA (up to 8 hours) or Shure SB900A rechargeable (up to 9 hours)
• Encryption: 256-bit AES encryption

Specifications

• Frequency band: G50 (470–534 MHz)
• Audio frequency response: 20 Hz – 20,000 Hz
• Dynamic range: > 130 dB (A-weighted)
• RF output power: 1 mW / 10 mW / 20 mW (switchable)
• Receiver dimensions: 197 × 43 × 178 mm (7.8 × 1.7 × 7.0 in)
• Receiver weight: 0.7 kg (1.5 lb)
• Transmitter dimensions: 86 × 66 × 23 mm (3.4 × 2.6 × 0.9 in)
• Transmitter weight: 142 g (5.0 oz) without batteries

In the Box

• ULXD4 receiver
• Power supply
• 2× 1/4-wave antennas
• Rack-mount hardware
• Ethernet cable
• ULXD1 bodypack transmitter
