Electrovoice presents the next generation of ELX with its redesigned ELX200 series!

The ELX200-12P features high-efficiency Class-D power amplifiers (up to 1200 W) with integrated QuickSmartDSP, and delivers up to 130 dB SPL utilizing transducers designed and engineered by EV (12-inch EVS-12M woofer coupled with a DH-1C 1-inch titanium compression driver). Powered full-range models allow easy setup via four presets (Music, Live, Speech, Club), sub/top system-match crossovers, three-band EQ, five user-programmable presets (Store and Recall settings), visual monitoring of limiter status, input level control and meters, and master volume control to ensure optimal gain structure.

The ELX200 series offers professional Electro-Voice audio quality, precision control, and robust, EV-engineered components in an ultra-lightweight package – a truly potent blend of performance and portability.

Wireless control and monitoring via the new Bluetooth® QuickSmartMobile app* Control your sound while in front of your system. Quickly configure up to six ELX200 loudspeakers simultaneously, and receive immediate notification during critical performance conditions.

  • Perfect for both portable and installed applications
  • Lightweight package with heavyweight performance
  • QuickSmartDSP provides best-in-class processing via EV’s signature single-knob user interface with LCD
  • Electro-Voice-patented SST (Signal Synchronized Transducer) waveguide design combines a more compact footprint with enhanced acoustic performance

Speaker Dimensions (12")

  • Height: 16.3"
  • Width: 14.3"
  • Depth: 14.0"
  • Weight: 34.4 lbs
Available Color Black Connector Type (1) Stereo RCA Input, (2) XLR/TRS combo jack, and (1) XLR Coverage (Nominal -6 dB) H 90 ° Coverage (Nominal -6 dB) V 60 ° Crossover Frequency 1700 Hz Depth 344 mm Enclosure Material Polypropylene Family ELX200 Frequency Range (-10 dB) 51 Hz – 20 kHz Frequency Response (-3 dB) 57 Hz – 16 kHz Hz Grill 18 AWG steel with powdercoat Height 629 mm HF Transducer DH-1C 1-inch titanium compression driver LF Transducer EVS-12M 300 mm (12 in) Max. SPL/1m (calc) 130 dB Power Consumption 100 - 240 V~, 50 - 60 Hz, 1.8A Power Rating 1200 W Powered or Passive Powered
Shipping Weight 17.7 kg Speaker Type Full-Range Suspension (3) M10 suspension points Weight Net 15.6 kg
