Integrated Amplifier Luxman L-540, Tested, Cleaned, 100V

The amplifier has been thoroughly tested and cleaned, working faultlessly.

The general conditions are very good; light signs of use can be seen, but nothing major.

You will need a power converter for 240V to use it UK or the EU.

Some more information about it from The Vintage Knob:

Luxman's last really successful integrated amplifier: even a bestseller in those pre-bubble-bursting days of 1989.

Successful here is meant market-wise: sound-wise, both the L-540 and L-570 were here and there tagged as "reference", "absolute" or "State of the Art", thus topping the already very successful line that started two short years before the Alpine days with the L-550 series in 1981.

The L-540 and L-570 are visually identical but for the second pair of speakers and the phones output which the L-540 adds ; inside, they are, however, almost entirely identical.

The L-540 offers 2x 110W in Class AB, superlative componentry, a non-resonant composite chassis base, dual copper-plated Heat-Pipe cooling system, a big EI transformer, the STAR grounding circuit, ALPS tone & balance pots and a superb rosewood case.

Specifications:1. General System:Integrated Transistor AmplifierColour: 1=Silver, 2=Black:Champagne GoldPre AmplifierInputs:10 (Phono MM/MC; CD; Tuner; Tape1/DAT; Tape 2+3; Line 1-3)Quadro:noInp. Sensitivity High Level:150 mVInp. Impedance High Level:50 kΩFrequency Response High Level:10-100,000 (-1 dB) HZSignal/Noise High Level:108 (IHF) dbInp. Sensitivity Phono MM:2.5 mVInp. Impedance Phono MM:50 kΩFrequency Response Phono MM:20-20,000 (+0.3 dB)Signal/Noise Phono MM:86 (IHF) dbInp. Sensitivity Phono MC:0.1 mVInp. Impedance Phono MC:100 kΩSignal/Noise Phono MC:74 (IHF) dbOutput Voltage Pre Out:150 mVEqualizerTone Controls:Bass; TreblePower AmplifierContinuous power 8Ω:100 + 100 WattsHarmonic Distortion:0.015 % at rated output2. PhysicalDimensions in Inches:17.2 x 6.9 x 18.4 (w) x (h) x (d)Dimensions in mm:438 x 176 x 467 (w) x (h) x (d)Weight in lbs:52.9 lbsWeight in Kg:24 Kg

Disclaimer:

Although I take every precaution in managing my hi-fi and hi-end products, there is a possibility that small scratches may occur during display and storage. I try to check and describe them as much as possible, but I cannot guarantee that every single part is a genuine product.

In addition, what is in the image is all that is in the product. Please be sure to check the image as the current state of the accessories and exterior condition will take precedence. I try to describe the condition of the product, such as scratches, sunburn, and dirt, as much as possible, but I may overlook them. It is not realistic to perfectly describe all of the product conditions.

Therefore, please be sure to check the condition of the product in an enlarged image. Scratches, sunburn, dirt, etc. that can be seen in an enlarged image are not a reason for return.

In addition, I do not accept returns due to minor scratches, sunburn, dirt, etc. that are difficult to see even in an enlarged image. What is in the image is all that is in the product. Scratches, dirt, defective screws, peeling of glue, etc. on the inside and bottom that are not photographed. Deterioration due to aging. These parts that do not affect the function of the audio equipment are not covered by the warranty.
