Rare Vintage Pioneer ER-420 AM/FM Tube Receiver-Tested-Cosmetically Mint-S. Video
Rare Find
These don't show up often
Our users rate Reverb
The Pioneer ER-420 is a vintage AM/FM stereo tube receiver produced around 1966–1970. It delivers 15 watts of RMS power per channel into 16 ohms with a total music power rating of 40 watts, featuring a classic vacuum tube design
Amplifier and Audio Specs
- Power Output: 15 watts per channel into 16Ω (stereo)
- Frequency Response: 20 Hz to 20,000 Hz (±1 dB)
- Total Harmonic Distortion: < 1% at 1 kHz
- Input Sensitivity: 2.7mV (MM phono), 29mV (ceramic phono), 200mV (line/aux)
- Speaker Impedance: 8Ω to 16Ω
Tuner Specs
- FM Tuning Range: 88 MHz to 108 MHz
- MW (AM) Tuning Range: 535 kHz to 1605 kHz
- FM Sensitivity: 2.0 µV
Tube Complement & Build
- Vacuum Tubes Used: 5 × 12AX7, 4 × 6BQ5 (plus additional IF/RF tubes like 6AQ8, 6BA6, 6AU6, 6BE6, 6AV6)
- Power Consumption: 154 W
- Dimensions:17.5 × 6 × 17.5 inches (445 × 152 × 445 mm)
- Weight:Approx. 35 lbs (15.7 kg – 17 kg)
Wide shipping!
PLEASE SEE PICTURES & VIDEO FOR CONDITION!
AS SEEN IN VIDEO THE UNIT IS COSMETICALLY IN MINT CONDITION AND WORKS! ALTHOUGH UNIT IS WORKING, BECAUSE OF AGE, I SUGGEST CLEANING PODS / SERVICE.
If you have any questions, please feel free to contact me & take a look at my other Listing!
Sold as is!
Thank you for looking.
Line: H4060200
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
