QSC power amp Model GXD8 NEW , 800 watts per channel at 8 ohms ( Dynamic 1500 watts par Channel at 8 Ohms)
->The price shown is for each unit
->Several units available
->See all the photos
->Serious inquiries please.
->Shipping prices outside the United States and Canada are indicated by a fictitious amount
of $5. To get your shipping price, you must give us your complete delivery address (street address, city, state, country and your code)
->The Price Indicated for transport may vary depending on the region where you are located.
->All our products are shipped in safe quality packaging.
QSC GXD8 Features;
800W/channel @ 8 ohms, 1200W/channel @ 4 ohms, 4500W total peak power
Power levels matched to the most popular speakers & optimized for maximum headroom
Class D output stage with USP for high performance/efficiency
Extensive and powerful DSP including high- and low-pass filters, 4-band parametric EQ, limiting & delay Precision rotary encorders for gain and DSP control
QSC GXD8 Specifications;
Stereo Mode - Watts Per Channel:
8 Ohm Peak, Both Channels Driven: 1500 Watts
4 Ohm Peak, Both Channels Driven: 2250 Watts
8 Ohm Continuous, Both Channels Driven: 800 Watts
4 Ohm Continuous, Both Channels Driven: 1200 Watts
Distortion (typical, 1 kHz at full rated power): < 1% THD
Signal-to-Noise Ratio (A-weighted, 20 Hz - 20 kHz): 100 Db
Input Sensitivity: 1.2 Vrms, 3.9 Vrms
Voltage Gain (8 Ohms): 33.5 dB
Output Circuitry: Class D
Power Requirements - 1/8 Power at 4Ohms
100 VAC: 6.2 Amps
120 VAC: 5.6 Amps
230 VAC: 3.2 Amps
Frequency Response: 20 Hz - 20 kHz, +0.7 dB,-0.8 dB
Dynamic Headroom (4 Ohms): 2.73 dB
Damping Factor: 100
Input Impedance: 20 kOhms (balanced), 10 kOhms (unbalanced)
Maximum Input Level: +23.5 dBu
Input Connectors (each channel): 3-pin XLRF / 1/4" TRS, balanced
Output Connectors (each channel): NL4 (Channel1 - 1+/-, Channel 2 - 2+/-), binding posts
Amplifier and Load Protection:
Short circuit
Open circuit
Thermal
RF protection
Load protected against DC faults
Front Panel Controls and Indicators:
2x Rotary Encoders
3x Operational Buttons (HOME, ENTER, EXIT)
2x Green Signal LEDs, indicates signal presence
2x Red A/D Clip LEDs, indicate input over-drive and/or amplifier current clipping
Blue Power LED ring, AC on
2.12" x 1.0", 256 x 128 pixel LCD panel
DSP Functions:
High Pass Filter, 4th order LR, adjustable Frequency 20 Hz to 4 kHz
Low Pass Filter, 4th order LR, adjustable Frequency 60 Hz to 4 kHz
4-band PEQ, with variable Frequency, Gain, and Bandwidth
Peak Limiter, with Power, Agressiveness, and Impedance selection
Delay 50 msec max
Dimensions (H x W x D): 3.5" (2U) x 19" x 10.2" (89 x 483 x 259 mm)
Weight: 13.2 lbs. (6.0 kg)
Agency Approvals: UL, CE, RoHS/WEEE Compliant
Carton and Contents: Power cable and quick start guide
This item is sold As-Described
This item is sold As-Described and cannot be returned unless it arrives in a condition different from how it was described or photographed. Items must be returned in original, as-shipped condition with all original packaging.Learn More.
