dbx ZonePRO 1260 Digital Zone Processor 6 Zone Digital mixer

DBX  Zone Pro 1260 Digital Zone Processor

Fully working 100%.

**Has some minor color wear around zone control buttons as you see in photo 1.

Doesn't affect operations of the unit. **

Comes with Phoenix rear terminal connectors as well as AC cable.
Fully tested with ZonePro Designer 3.3 software for proper networking operations.

Features:

• Advanced Feedback Suppression (AFS™)
• Autowarmth®
• Auto Gain Control
• Compression
• Limiting
• Noise Gating
• Notch Filtering
• Bandpass and Crossover Filters
• Parametric EQ
• Security Lockout
• Wall Panel Control
• RS-232 Control
• IEC, UL and CSA Approvals

Specifications

Input12 Total (2) Switchable mic or line, (8) RCA, and (1) S/PDIF

Input Connectors Euroblock (Line and Mic) RCA (Source)

Input Impedance Euroblock > 50kΩ Balanced, >25kΩ Unbalanced, RF Filtered; RCA >25kΩ Unbalanced, RF Filtered

Max Input+20dBu Mic/Line, +12dBu RCA

CMRR> 40dB, typically >55db @ 1kHz

Mic Preamp gain30 to 60dB

Mic Preamp Equivalent Input Noise (EIN)<-118dB

Mic Preamp Phantom Power15VOutput6 Analog

Output ConnectorsEuroblock

Output TypeElectronically balanced, RF filtered

Output Impedance120 ohms balanced, 60ohm unbalanced

Max Output+20dBu

A/D Converterdbx Type IV™ conversion system

A/D Dynamic Range(line) >113 dB, A-weighted, >110 dB unweighted

Type IV Dynamic Range>119 dB, A-weighted, 22kHz BW; >117 dB, A-weighted, 22kHz BW

Sample Rate48kHz

D/A Dynamic Range112 dB A-weighted, 109dB unweighted

Dynamic Range>110 dB A-weighted, >107dB unweighted

THD+Noise0.003% typical at +4dBu, 1kHz, 0dB gain

Frequency Response20Hz - 20kHz, +/-0.5dB

Interchannel Crosstalk>80dB typical

Propagation Delay0.6 msec

Operating Voltage100-240 VAC, 50/60Hz

Power Consumption27 W

Unit Weight6.8 lbs.(3.1 kg)

Shipping Weight8.8 lbs. (4.0 kg)

Dimensions1.75” H x 5.75” D x 19” W

Safety Agency Certifications UL 60065, IEC 60065, E 60065, EN 55013

Thanks For Looking   ! ! !
