Advanced Creative Tools for Studio-Grade Tube Amp Tones - The BOSS WAZA Tube Amp Expander Core

The WAZA Tube Amp Expander Core is a professional recording solution for capturing tube amp tones with exceptional quality. BOSS's Tube Logic approach and reactive load design retain your amp’s natural feel and touch response, while premium cab emulation and studio processing make it simple to craft high-impact direct sounds. Creative options include a helpful Mix Assist tool that ensures tracks fit perfectly within every mix, plus a unique Air Feel feature that authentically recreates “amp-in-room” sound with advanced spatial technology. And with the integrated 30-watt reactive drive power amp and your favorite cab, you can enjoy “sweet spot” amp tones at home-friendly levels.

• Next-generation V-Guitar processor with the Serial GK interface
• Latency-free performance and independent string processing with divided pickup technology
• Hyper-realistic stringed instrument modeling, including electric and acoustic guitars and basses, banjo, and sitar
• Dual guitar and bass functions for creating simultaneous combinations that are impossible with standard instruments
• Freely change the tuning for each string independently
• Harmony function for creating rich ensemble sounds with single notes or chords
• Dedicated guitar and bass modes
• Individual string bend function for performing dynamic pitch effects with a footswitch or expression pedal
• Massive selection of amps and effects derived from flagship BOSS guitar/bass processors
• Modeled synth sounds, including a detailed emulation of the classic Roland GR-300 analog guitar synth
• VIO Guitar and VIO Bass for creating unique sounds with bowed attack characteristics
• TRS send/return jacks for integrating external mono or stereo pedals
• USB-C® audio/MIDI interface and TRS MIDI I/O
• Guitar-to-MIDI and bass-to-MIDI functions
• Two external control jacks, each with support for up to two footswitches or an expression pedal
• Guitar input for using standard guitars and basses with VG-800 amps and effects (instrument modeling functions are not available with this input)
• Serial GK output for interfacing with products such as the GM-800 Guitar Synthesizer
• BOSS Tone Studio editor software (Windows/macOS)
• Download and share sounds on BOSS Tone Exchange

SPECIFICATIONS

• Maximum Input Power: FROM TUBE AMP: 100 W
• Safety Load (power off): FROM TUBE AMP: 330 ohms
• Rated Power Output: TO SPEAKER: 30 W (8 ohms)
• Load Impedance: TO SPEAKER: 4-16 ohms
• Input Impedance:
  • FROM TUBE AMP: 8 ohms
  • FX LOOP RETURN: 1 M ohm
• Output Impedance:
  • LINE OUT L/R: 600 ohms
  • FX LOOP SEND: 1 k ohm
• Nominal Output Level: LINE OUT L/R: +4 dBu
• FX LOOP Nominal Input/Output Level: -10/+4 dBu (selectable)
• Maximum Output Level:
  • LINE OUT L/R: +13 dBu
  • FX LOOP SEND: +6 dBu (-10) / +20 dBu (+4)
• Controls:
  • POWER switch
  • SPEAKER OUT knob
  • LINE OUT knob
  • PHONES knob
  • REACTIVE LOAD knob
  • RIG knob
  • AIR FEEL LEVEL knob
  • WRITE button
  • INPUT LEVEL switch
  • FX LOOP LEVEL switch
  • GND LIFT switch
• Indicators:
  • POWER
  • WRITE
  • INPUT SIG/PEAK
• Connectors:
  • FROM TUBE AMP jack: 1/4-inch phone type
  • TO SPEAKER jack: 1/4-inch phone type
  • LINE OUT L/R connectors: XLR type
  • PHONES jack: Stereo 1/4-inch phone type
  • FX LOOP SEND jack: 1/4-inch phone type
  • FX LOOP RETURN jack: 1/4-inch phone type
  • USB port: USB Type-CⓇ
  • MIDI IN connector
  • Bluetooth adaptor connector: Dedicated connector
  • DC IN jack
• Power Supply: AC adaptor
• Current Draw: 470 mA
• Dimensions (including foots): 200 (W) x 202 (D) x 99 (H) mm / 7-7/8 (W) x 8 (D) x 3-15/16 (H) inches
• Weight: 2.2 kg / 4 lbs 14 oz
• Accessories:
  • Owner's manual
  • AC adaptor
  • Power cord

Manufacturer: Boss
Model: W-TAE CORE
SKU: I811767-N-3-WHXC
UPC: 761294520994
