4 ohm hemp cone speaker with rich, warm, full bodied tone with fat, punchy lows, smooth, but defined highs, and a nice break up. Prominent mids, but with a warm, smooth texture.
- speaker_size: 8
- Basket Diameter in: 8
- Basket Diameter_mm: 203
- Nominal Impedance: 4
- Power Rating_Watts: 20
- Power Rating_Music Program: 40
- Resonance: 144
- Freq Range HZ: 80
- Freq Range kHZ: 4.6
- Sensitivity dB: 96.1
- Mag Wt_oz: 15
- Gap Height_in: 0.25
- Gap Height_mm: 6.4
- Voice Coil_Diam_in: 1
- Voice Coil Dia_mm: 25
- fs: 144
- Re: 3.64
- Le: 0.33
- Qms: 18.78
- Qes: 0.92
- Qts: 0.88
- Vas_ltr: 9.62
- Vas_cuft: 0.34
- VD: 36.7
- Cms: 0.13
- BL: 5.74
- Mms: 9
- EBP: 156
- Xmax: 1.59
- Sd: 230.9
- Xlim:
- Enc Recom Sealed: ACCEPTABLE
- Rec Enc Volume_Sealed Min_liters:
- Rec Enc Volume_Sealed Max_liters:
- Rec Enc Volume_Sealed Min_cuft:
- Rec Enc Volume_Sealed Max_cuft:
- Enc Recom Vented: ACCEPTABLE
- Rec Enc Volume_Vented Min_liters:
- Rec Enc Volume_Vented Max_liters:
- Rec Enc Volume_Vented Min_cuft:
- Rec Enc Volume_Vented Max_cuft:
- Drive Volume Displaced_liters: 0.51
- Driver Volume Displaced_cuft: 0.018
- Overall_Diam_in: 8.24
- Overall_Diam_mm: 209.3
- Baffle Hole_Diam_in: 7.13
- Baffle Hole_Diam_mm: 181.1
- Front Seal Gask: Yes
- Rear Seal Gask: N/A
- Mounting Holes_Diam_in: 0.22
- Mounting Holes_Diam_mm: 5.6
- Mounting Holes_BCD_in: 7.75
- Mounting Holes_BCD_mm: 196.9
- Depth_in: 3.06
- Depth_mm: 77.7
- Net Weight_lbs: 3.1
- Net Weight_kg: 1.41
- Ship Weight_lbs: 3.9
- Ship Weight_kg: 1.77
- Coil Construction: Copper voice coil
- Coil Former: Polyimide former
- Magnet Comp: Ferrite magnet
- Core Details: Non-vented core
- Basket Material: Pressed steel basket
- Cone Composition: Paper cone
- Cone Edge Composition: Full paper cone
- Dust Cap Composition: Zurette dust cap
- coloration:
- Genre:
- Model Group: Patriot Guitar
- Subwoofer Usage:
- Woofer Usage:
- MidBass Usage:
- Midrange Usage:
- Bass Guitar:
- Closed box:
- Reflex Box:
- Scoop Loading:
- Horn Loading:
