Double Your Switching Power

Two switches in one, BOSS’s new FS-6 combines latch- andmomentary-type switching into one unit. With two switches convenientlyhoused side-by-side, the FS-6 allows each switch to be set for latch ormomentary operation. Pick the configuration that best suits your playingstyle and setup.

• Each footswitch can be assigned latch- or momentary-type
• Stereo input jack for single stereo cable connection
• Can be connected to other footswitches (FS-5L/FS-5U/FS-6/AB-2) for extension
• Connect to a wide variety of instruments, rhythm machines, guitar amps, and electronic devices that have control input jacks compatible with FS-5L/FS-5U

Controls Pedal Switch A, B / POLARITY Switch A, B / Mode Switch A, B Connectors Jack A, Jack B (1/4 inch phone type)
Jack A & B (TRS 1/4 inch phone type) Power Supply DC 9 V: Dry battery/9 V 6F22 (carbon), 6LR61 (alkaline) Current Draw 8 mA (max.) Accessories Dry battery/9 V (6F22), Owner's Manual Size and Weight ( incl. battery ) Width 188 mm
7-7/16 inches Depth 91 mm
3-5/8 inches Height 43 mm
1-3/4 inches Weight 470 g
1 lbs. 1 oz.
