KEYBOARD, BASS & BELLOWSRight hand41 keys: piano type with velocity sensitive and aftertouchLeft handPiano type/Button type 120 bass buttons velocity sensitive. Standard, Free Bass mode, Orch. Bass, Orch. Chord, Orch. Free BassBass & Chord Mode2 Bs Rows, 3 Bs Rows A-7th, 3 Bs Rows A-5dim, 3 Bs Rows B-7th, 3 Bs Rows B-5dim, 3 Bs Rows Bx-7th , 3 Bs Rows BelgiumFree Bass ModeMinor 3rd, Bajan, Fifth, North Europe, FinnishBellowsAdvanced “Dynamic Bellows Behavior” technology to manage the behavior of bellowsBellows ResistanceOn, Off, -63 to 0 to +64Bellows curveFixed Low, Fixed Med, Fixed High, X-Light, Light, Standard, Heavy, X-HeavySOUND SOURCEMax polyphony128 voicesTones (Accordion Set)100 Accordion Sets, each one including: 14 Treble Registers, 7 Bass/Chord registers, 7 Free Bass registers, 7 Orchestra Free Bass registers, 7 Orchestra Bass registers, 7 Orchestra Chord registers, 180 Orchestral sounds (28 real time + others selectable by MENU), 18 Drum SetsReed Footages7 Treble, 5 Bass, 3 Chord, 2 Free BassAdditional soundsUpload from USB memory and saved on internal memoryOrchestral sounds180: 28 real time (14x2) the others selectable by MENUOrgan sounds (Virtual Tone Wheel)32 presets for Treble, Chord and Free Bass sections, 16 presets x Bass section
Up to 28 Harmonic Bar combinations customizable, can be controlled and shaped by bellows.Orchestral Bass sounds180: 7 real time, the others selectable by MENUOrchestral Chord sounds180: 7 real time, the others selectable by MENUOrchestral Free Bass sounds180: 7 real time, the others selectable by MENUDrum Sets18User Programs1,400: 100 User Program Bank x 14 registersAPBM (ADVANCED PHYSICAL BEHAVIOR MODELING)NoisesStopping-reed growl, Closing valve noise, Left button noiseIndividual Reed SimulationHysteresis threshold, Expression curve, Pressure variant filter, Pressure variant pitch deviationSwitching Reed Sound WaveBy bellows acceleration, by note repetition speedBellows opening/closing sound changeBy bellows opening/closing detectionBellows BehaviorDynamic Bellows Behavior technology for a perfect simulation of the bellows behavior in an acoustic accordionMUSETTE TUNINGMicro-Tuning Presets16 Types: Off, Dry, Classic, F-Folk, American L/H, North Europe, German L/H, D-Folk L/H, Alpine, Italian L/H, French, ScottishFine Tuning reed footages 8- / 8+-100 to 0 to +100EFFECTSReverb/Chorus/Delay8 types, 8 types, 10 typesMFX multi effectsMFX x 4 (84 types) for: Accordion, Orchestra 1, Orchestra 2, Orch Chord/Orch Free BassRotary for Organ soundSlow/Fast with Vibrato, Chorus, Overdrive and VK-Rotary“Cassotto” simulationYesPANEL CONTROLSKnob controls & RegistersVolume, Balance, Reverb Chorus, Delay, Effect (assignable knob), 14 x Accordion/Orchestra1/Orchestra2/OrganEncoderData Edit with EnterNavigation switchesUp, Down, Menu/Write, Exit/JumpOther switchesSet Up, Set Down, Orch 1 On/Off, Orch 2 On/Off, Organ On/Off, Accordion On/Off, Orch Bass On/Off, Orch Chord/Free Bass On/Off, Free Bass On/Off, Bass&Chord On/Off, Drums On/Off, Bass to Treble On/Off, User Program On/Off, Song List On/Off, Power On/Off, Charge On/Off, Loop/Wave/MP3 player: Loop, Reset/Stop, Play/Pause, Audio RecChin switches3 programmable chin switchesAdditional switches6 user assignable function switches on last row of bass buttonsOPERATION MODEAccordion, Orchest1/Organ, Orchest2, DrumZone, High, LowOctave-1, 0, +1 for Treble, -3, 0, +3 for Orchest1, Orchest2Drum Shift-36 to 0 to +36Orchestra Chord Guitar ModeGtr Table1, Gtr Table2, Gtr Table3Sound EditOrchest1, Orchest2, Orch Bass, Orch Chord, Orch Free BassBass to TrebleOn/OffPart MuteAccordion, Orchest 1, Orchest 2, Organ, Bass&Chord, Free Bass, Orch Bass, Orch Chord, Orch Free BassBass & Chord with drum/percussion soundsProgrammable drum/percussion sounds for Bass/Orch Bass 2 rows, Chord/Orchestra Chord 4 rows.Audio Player and Audio RECMP3/Wave player from USB memory and REC on USBAudio LoopREC (with Overdub function) and PlaySpeakers OffOn/Off adjustable via Menu parameterEditing and WriteFull parameters for each section – New Graphic User InterfaceMIDI FUNCTIONSExt. Seq. Playback (MIDI IN) or USB ComputerAccordion, Bass&Chord, Orchest1, Orchest2, Organ, Orch Bass, Orch Chord, Orch Free Bass, ALL (Local Off function)Start/Stop MIDI TXSend Start/Stop by pushing Alpha dialOTHERDisplayColor LCD 2.4”, 320 x 240 dotsRated Power Output2 x 25 WSpeakers2 x 9 cm neodymium speakers
2 x TweetersWave Expansion4 internal areas (8 MB each) to load new soundsPower supplyAC adaptor
Rechargeable Ni-MH battery pack 24 V – 4500 mA

* Expected battery life under continuous use: 8 hours speaker ON mode, 11 hours speaker OFF modeOnboard ConnectorsOUTPUT jacks L/Mono (Treble), R/Mono (Bass): 1/4” phone type
PHONES jack: 1/4” phone type
MIDI (IN, OUT) connectors
USB MEMORY port: type A
USB COMPUTER port: type B
DC IN connectorAccessoriesAC Adaptor
Power cord (for connecting the AC adaptor)
Rechargeable Ni-MH battery pack 24 V – 4500 mA
Owner’s Manual
Reference caps for the bass buttons
Straps
Accordion cloth
Accordion soft bagOption (sold separately)Wireless USB Adaptor (WNA1100-RL)
USB flash memory (M-UF2G)
Headphones: RH-200, RH-300
Rechargeable Ni-MH battery pack 24 V – 4500 mA
FootswitchSIZE AND WEIGHT (WEIGHT: WITHOUT STRAPS)Width543 mm
21-7/16 inchesDepth280 mm
11-1/16 inchesHeight415 mm
16-6/16 inchesWeight12.1 kg
26 lbs. 11 oz.
