Pinstripe Pedals DISO+ DLX Deluxe Line Isolator

The complete stereo line isolation solution for modern rigs

The Pinstripe Pedals DISO+ Deluxe is a professional two-channel line isolator designed to connect modern pedalboard rigs, amp modelers and other line-level equipment directly to a PA system without unnecessarily converting the signal to microphone level.

Unlike a conventional DI box, which is designed to provide impedance matching while reducing the signal to mic level, the DISO+ Deluxe maintains your line-level signal while adding transformer isolation, ground lifting and balanced XLR outputs. This makes it an ideal interface for devices such as the TONEX, Strymon Iridium, Universal Audio amp pedals, Line 6 HX Stomp, Walrus ACS1, Boss IR-2 and IR-200, as well as other modelers and DSP-based guitar rigs.

At the heart of the DISO+ Deluxe are two US-made Cinemag transformers, providing galvanic isolation between your pedalboard and the equipment downstream. This helps eliminate ground-loop hum while preventing phantom power from the mixing console from reaching the outputs of your pedals.

Two 1/4" inputs feed both balanced XLR and 1/4" outputs, allowing the DISO+ Deluxe to function as a convenient connection point between your pedalboard, front-of-house system and stage monitoring. The 1/4" outputs can be connected to powered monitors, FRFR speakers or other line-level equipment without having to repatch your board.

The Deluxe version adds independent summing options for both sets of outputs. The 1/4" summing switch lets you combine the left and right signals for connection to a single amp or FRFR speaker while keeping the XLR outputs in stereo. A separate XLR Summing switch makes it possible to quickly switch the XLR feed between stereo and mono when required.

A Polarity Reverse switch is also provided for the Left XLR output, making the DISO+ Deluxe particularly useful with stereo rigs built around devices that can produce polarity differences between their two signal paths.

Built by hand in the USA with Cinemag transformers, Switchcraft and Neutrik connectors, and Grayhill switches, the DISO+ Deluxe is designed as a transparent, reliable interface for professional pedalboard rigs. Whether you're connecting to front of house, powered monitors or an FRFR system, it provides a simple way to keep your signal clean, quiet and at the proper level.

Pinstripe Pedals DISO+ Deluxe Features

• Professional two-channel line isolator for stereo and dual-mono rigs

• Maintains line-level signals without the level reduction of a conventional DI box

• Two US-made Cinemag isolation transformers

• Balanced XLR outputs for connection to PA and professional audio equipment

• 1/4" outputs for powered monitors, FRFR speakers and other line-level equipment

• Ground lift helps eliminate ground-loop hum

• Transformer isolation protects connected equipment from phantom power

• XLR Summing switch allows quick switching between stereo and mono operation

• 1/4" Summing switch combines left and right signals for connection to a single amp or FRFR speaker

• Polarity Reverse switch for the Left XLR output

• Can function as a convenient pedalboard patch point for stage and rehearsal setups

• Switchcraft and Neutrik connectors

• Grayhill sealed switches

• Dimensions: 4.7" × 3.7" × 1.56"
