ATC Loudspeakers SCM20ASL Pro MK2 2-Way Studio Monitor - Pair #3747/3746 (Used)

VINTAGE KING APPROVED

This item has been carefully inspected, tested and serviced by our expert tech team. All vintage, used and open-box items we sell are backed by an industry-leading warranty. Expand your studio with confidence knowing that we have you covered.

ATC Loudspeakers SCM20ASL Pro MK2 2-Way Studio Monitor - Pair #3747/3746 (Used)

The ATC SCM20A Pro is a active two-way studio monitor that combines outstanding bass response and dynamic range in a compact package. Equipped with a groundbreaking 6.5-inch Super Linear mid/bass driver, a 1-inch dual-suspension S-spec tweeter and an all-discrete MOSFET class A/B amplifier, SCM20ASL monitors deliver balanced, neutral sound with astonishgly low distortion.

S-SPEC TWEETER

The ATC SCM20ASL Pro features a 1-inch soft dome S-spec tweeter with an innovative dual suspension design for pristine high-end. S-spec tweeters combine an exceptionally powerful motor assembly with a lightweight coil former for an extended frequency range up to 25 kHz. Unlike conventional tweeters, S-spec tweeters offer far greater control of the voice coil and dome motion—especially at higher sound pressure levels. By reducing internal distortion, S-spec tweeters deliver improved clarity and definition, and significantly reduce listener fatigue. And with zero ferro fluid, these tweeters are guaranteed to last a lifetime.

SUPER LINEAR DRIVER

ATC SCM20A Pro studio monitors are equipped with a state-of-the-art 6.5-inch Super Linear mid/bass driver for tight, powerful low end. With a unique underhung voice coil design, Super Linear drivers produce extremely low distortion, even at high SPLs. SCM20A Pro studio monitors feature a 150mm bass cone with a grafted 75 mm soft dome to for an extremely wide dynamic range, making them an excellent choice for post production projects.

IMPRESSIVE AMPLIFICATION

ATC SCM20A Pro studio monitors use an innovative bi-amplified design to provide 300 total watts of power for crystal-clear distortion-free sound. With 250W powering the Super Linear mid/bass driver and an additional 50W for the S-spec tweeter, SCM20A Pro studio monitors offer impressive headroom and class-leading transparency at any volume level.

FEATURES:

• Drivers: LF 6.5”/150 mm Super Linear, HF 1”/25 mm Dual-Suspension ‘S-Spec’ Tweeter
• Amplitude linearity: 80 Hz – 20 kHz (±2 dB)
• Cut-off frequencies: 55 Hz – 25 kHz (-6 dB freestanding)
• Dispersion: ±80° coherent horizontal, ±10° coherent vertical
• Maximum continuous: SPL 108 dB (per pair @ 1 m)
• Audio input: Rear panel mounted female XLR (pin 2 +ve)
• Input sensitivity: 1 V/2 V RMS or +2.2/+8.2 dBu via switch (ref. bass full output)
• Input sensitivity trim: 0 dB to -6 dB (via rear panel pot)
• Total input sensitivity range: 1 V/+2.2 dBu to 4 V/+14.2 dBu
• Input impedance: 10 kΩ per leg
• Amplifier output power: Bass 200 W continuous, HF 50 W continuous (1% THD)
• Crossover frequency: 2.1 kHz
• Crossover filters: 2nd order/12 dB/oct critically damped with phase compensation
• Low frequency shelf cut/boost: 80 Hz, -2 dB to +3 dB in 1 dB steps (via rear panel rotary switch)
• Overload protection: Active FET momentary gain reduction (inc. front panel mounted ‘limit’ LED)
• Amplifier thermal trip circuit
• Cabinet Dimensions (HxWxD) : 450 x 250 x 392 mm (17.7″ x 8.8″ x 15.4″)
• Weight: 28 kg/61.6 lb (per cabinet)

USED ITEM WARRANTIES

Vintage King offers an industry-leading level of technical service and warranty support on our used and vintage items. Our used item warranty periods are as follows:

• Analog Outboard Gear – 1 Year
• Microphones – 1 Year (excluding capsules, tubes, and ribbon elements)
• Speakers – 1 Year (excluding drivers)
• Digital Outboard Gear – 30 Days
