JBL AWC159 All-Weather Compact 2-Way Coaxial Loudspeaker with 15 LF Black

JBL AWC159 All-Weather Compact 2-Way Coaxial Loudspeaker with 15" LF (Black)

The AWC159 is a rugged, professionally engineered loudspeaker designed for permanent installation in demanding studio and location recording environments. Its compact footprint and coaxial design deliver consistent, phase-coherent coverage and high output from a single enclosure, making it ideal for field recording, live tracking sessions, and architectural installations where weather resistance and sonic reliability are non-negotiable.

Design & Build Quality

Constructed from ABS plus fiberglass with heavy internal bracing, this speaker meets IP56 environmental protection standards and withstands sustained exposure during outdoor and mobile recording setups. The 486 × 486 × 479 mm cabinet (20.6 kg) accepts standard barrier terminal wiring up to 12 AWG and mounts securely with included bracket hardware for flexible studio and location deployment.

Recording & Mix Integration

The 380 mm woofer with Kevlar-reinforced cone pairs with a 38 mm compression driver in a coaxial configuration, producing 98 dB sensitivity and peak SPL of 131 dB at 1 meter. Selectable 70V/100V multi-tap transformer or direct 8Ω operation accommodates both distributed session setups and dedicated amplifier configurations, while the 1.5 kHz crossover ensures seamless driver integration across the 80 Hz–20 kHz response range for accurate monitoring and reference.

Key Features

• 380 mm (15 in) Kevlar-reinforced woofer with 75 mm voice coil
• 38 mm (1.5 in) compression driver with high-temperature polymer diaphragm
• 300 W 70V/100V multi-tap transformer or 8Ω direct operation
• 500 W system power rating (2000 W peak); 300 W / 100 hrs continuous
• Frequency response ±3 dB: 80 Hz–20 kHz; −10 dB range 52 Hz–20 kHz
• 98 dB sensitivity (2.83V @ 1m averaged 80 Hz–20 kHz)
• Maximum SPL: 125 dB direct 8Ω (131 dB peak)
• 90° × 90° coverage pattern with 1.5 kHz, 4th-order crossover
• IP56 environmental protection rating per IEC 529
• ABS plus fiberglass enclosure with heavy internal bracing
• Barrier terminals accept 12 AWG wire, #6 or #8 open lugs, and 2.5 mm² spade connectors
• Dimensions: 486 × 486 × 479 mm; depth 546 mm with bracket; net weight 20.6 kg (45.5 lbs)

The AWC159 combines professional-grade components, all-weather durability, and flexible amplifier compatibility into a compact loudspeaker engineered for location recording, remote sessions, and mobile studio deployments.
