Fame MS-Antenna AD-900 Grid - Wireless System Accessory

• Broadband antenna distribution system for UHF range 450-950 MHz
• Active directional antenna with gain control (-16 to +16 dB in 1 dB steps)
• Supports 2-4 wireless systems per unit
• Cascade connection for the operation of an additional system or a 5th receiver
• Low noise: Built-in low-noise amplifier (<0.6 dB) for clear signal transmission
• High linearity: OIP3 amplifier >38 dBm, prevents intermodulation interference
• Precise circuitry for low distortion and robust multi-channel performance
• Heart-shaped directional characteristic for targeted reception of large areas
• Real-time voltage Display for monitoring voltage stability
• Universal compatibility with all UHF wireless microphone systems in the frequency range
• Flexible mounting on tripod or wall bracket, compact and transport-friendly design

With the MS-Antenna AD-900, FAME is launching a high-quality antenna distribution system that is specially designed for professional wireless operation in large environments. By using just one pair of antennas, several receivers can be operated in parallel, which not only simplifies installation but also increases the efficiency of the entire system.

The active directional antenna significantly improves the received signal and reliably compensates for cable length losses. Thanks to the gain control of -16 to +16 dB, the amplification can be precisely adapted to the respective situation - whether for short cable runs or long distances. This means that the signal always remains stable, even in demanding environments with many sources of interference.

Thanks to the low intermodulation distortion, the AD-900 is particularly suitable for the simultaneous operation of several radio channels without causing mixed interference. This makes the system the ideal solution for complex wireless setups, such as those required in theaters, on concert stages, at festivals or sporting events.

The robust design, simple handling and universal compatibility with almost all UHF wireless microphone systems make the FAME MS-Antenna AD-900 an indispensable tool for professional sound engineers and event technicians.
