FEATURES

â�24-bit 44.1kHz signal processing

â�Advanced digital modeling technology delivers organic tone

â�Over 140 high quality effects

â�Editable effect chain

â�45 legendary guitar/bass/acoustic amp types

â�40 factory IR cabinets

â�Supports storing 20 user IRs

â�50+ dynamic/drive/EQ/mod/delay/reverb effects

â�USB audio interface function with stereo audio streaming

â�Stompbox and preset modes for different situations

â�198 presets (99 factory, 99 user)

â�High quality looper

â�100 high quality drum patterns

â�Durable metal chassis and footswitches

â�Built-in chromatic tuner

â�Intuitive PC/Mac editor

â�1/4" stereo outputs

â�1/8" headphone output

â�Stereo 1/8" Aux Input

â�Built-in expression pedal

â�DC 9V power supply

SPECIFICATIONS

A/D/A Converter: 24-bit high performance audio

Sampling Frequency: 44.1 kHz

SNR: 110dB

Maximum Simultaneous Effects: 9

Preset Memory: 99 User Presets/99 Factory Presets

Looper: 90 seconds of record time

Drum Machine: 99 Patterns

Analog Input Connections

Guitar Input: 1/4" Unbalanced (TS)

Input Impedance: 1M Ohms

Aux Input: 1/8" Stereo (TRS)

Aux Input Impedance: 10k Ohms

Analog Output Connections

Left/Right Outputs: 1/4" Unbalanced (TS)

Left/Right Output Impedance: 1k Ohms

Headphone Output: 1/8" Stereo (TRS)

Headphone Output Impedance: 47 Ohms

Digital Connections

USB Port: USB 2.0 Type-B

USB Recording Specification

Sample Rate: 44.1 kHz

Bit Depth: Supports 16-bit or 24-bit

Dimensions: 198mm(W) x 134mm(D) x 28mm(H)

Unit Weight: 800g

Power: Power Requirements: DC 9V, 500mA (not included)

Package included: only the pedal (the original adapter is CN plug,do not have EU/US plug.but you can use your own adapter)
