• Stereo main output, four direct mono outputs, balanced for easy mixing on stage
• Connectivity for up to eight external individual triggers/pads (four stereo triggers or eight mono triggers with Y-cables)
• Dedicated SPD-SX PRO App for Windows/Mac for easy importing, managing samples, and deep kit editing
• 32 GB of internal storage for samples, backing tracks, and click tracks
• Input for hi-hat or footswitch expression control
• Connect hi-hats, kick, and snare for a 'mini drum kit' setup
• Up to 200 kit patches (43 erasable preset kits and 157 user kits)
• Over 1550 pre-loaded, high-quality samples and sounds
• 16-step pad sequencer function
• Onboard effects engine with up to four effects in parallel, plus side chain with output routing
• Built-in click/metronome
• Create in real time by recording performances as WAV files and assigning them to pads

Specs

- Pads
Built-in pads: 9 (with PAD LED, Vertical LED)
*Four external trigger inputs are provided, allowing you to connect up to eight pads with Y cable.

- Maximum Polyphony
32 voices (included click voices)

- Number of Recordable Wave Data
20,000
*Including preload data

-Internal storage
Size: 32 GB
*Including preload data

-Sampling Time
Sampling from AUDIO IN : 60 minutes per sample
Resampling : 10 minutes per sample

- Data Format
16-bit linear

- Sampling Frequency
48 kHz

-Import Format
WAV, AIFF, MP3

- Kits
200

- Preload wave
Factory preloaded samples: 1,550 or more

- Setlist
32 (32 steps per SET LIST)

- Kit Effects
Layer Equalizer : each pad (Layer A/B independently)
Layer Transient : each pad (Layer A/B independently)
Multi-Effects (53 types) : 4 systems
Side Chain Compressor : 1 system

- System Effects
Master Effects (53 types)
Master Compressor
Master Equalizer

-Number of USB Audio Record/Playback Channels
Sampling Rate (Original): 48 kHz
Sampling Rate (with Sampling rate converter): 96 kHz, 44.1 kHz
Record: 8 channels
Playback: 12 channels

- Display
Graphic colour LCD 4.3 inch

- Connectors
PHONES jack : Stereo 1/4-inch phone type
MASTER OUT (L, R)jacks (BALANCED) : 1/4-inch TRS phone type
DIRECT OUT jack x 4 (BALANCED) : 1/4-inch TRS phone type
AUDIO IN jack : Stereo 1/4-inch phone type (with Volume control)
TRIG IN jack x 4 (1/2, 3/4, 5/6, 7/8) : 1/4-inch TRS phone type
FOOT SW jack x 1 (1/2) : 1/4-inch TRS phone type
HH CTRL/EXPRESSION jack x 1 : 1/4-inch TRS phone type
MIDI (IN, OUT/THRU) connectors
USB COMPUTER port : USB B (High-Speed USB, USB-AUDIO, USB-MIDI, App)
USB MEMORY port : USB A (High-Speed USB, Backup Save/Load, Sample Import/Export)
DC IN jack

- Power Supply
DC 12V (AC Adaptor)

- Current Draw
1,500 mA

- Dimensions
360 (W) x 330.3 (D) x 92.9 (H) mm
14-3/16 (W) x 13-1/16(D) x 3-11/16(H) inches

- Weight
3.0 kg / 6 lbs 10 oz (excluding AC Adaptor)

- Accessories
Quick Start Leaflet "Read Me First"
AC Adaptor
