PIONEER SX-939 FM/AM STEREO RECEIVER FULLY SERVICED RECAPPED + LED'S
Rare Find
These don't show up often
Our users rate Reverb
YOU ARE BIDDING ON A TECHNICS SX-939 STEREO RECEIVER FULLY SERVICED RECAPPED + LED'S
EXCELLENT COSMETIC CONDITION ( however outer wood casing shows some wear see pic for full details )
LIGHTS UP NICELY
WORKS PERFECT
FULLY RE-CAPPED All electrolytic capacitors have been replaced with Elna and Nichicon Gold capacitors, DC offset and Bias have been adjusted to factory specs and all solder joints re-soldered, unit serviced to new condition
SHIPPING TO USA AND CANADA $50
INTERNATIONAL BUYERS MUST EMAIL FOR SHIPPING COST
Description
The Pioneer SX-939 is a highly versatile, big powered FM/MW stereo receiver.
The unit features a parallel push pull OCL power amplifier with less than 0.3% total harmonic distortion, a completely new PLL MPX circuit, frequency linear 4-gang variable capacitor and a newly developed IC AM.
It also has a twin control system and duplication switch, and Dolby adapter in/out terminals with switch.
Specifications
Tuning range: FM, MW
Power output: 70 watts per channel into 8Ω (stereo)
Frequency response: 10Hz to 40kHz
Total harmonic distortion: 0.3%
Damping factor: 45
Input sensitivity: 2mV (mic), 2.5mV (MM), 150mV (DIN), 150mV (line)
Signal to noise ratio: 65dB (mic), 70dB (MM), 95dB (line)
Output: 150mV (line), 30mV (DIN), 1V (Pre out)
Speaker load impedance: 4Ω (minimum)
Semiconductors: 3 x FET, 4 x IC, 57 x transistors, 39 x diodes
Dimensions: 520 x 175 x 420mm
Weight: 18.5kg
Accessories: FM T-type antenna
